Asparagus is a modular machine learning framework designed for medical imaging applications. The codebase is built on PyTorch, Lightning and Hydra and handles model training, experiment management, and evaluation with prepared data. To prepare your data see Preprocessing. The functional and modules directories follow the structure of torch.nn.functional and torch.nn with the former being stateless functions and the latter being classes that combine and build upon these with the logic and conventions adopted by Asparagus from PyTorch, Lightning, and Hydra.

Quick Navigation

Getting Started

1. Setup

Package installation

For a standard local editable installation:

git clone https://github.com/Sllambias/asparagus
cd asparagus
pip install -e .

To install Asparagus on Gefion, please refer to Installing Asparagus environment on Gefion.

Environment variables

To set up required and optional environment variables see: Environment Variables

2. Preprocessing

See the asparagus_preprocessing repository.

3. Training

Asparagus uses Hydra configs (see Hydra) to configure training runs. To use the default setup, 3 args are required:

• The Task to train on
• The model architecture to use
• The data split to use

These can be given either by creating a config that specifies them (see Config Reference), or at runtime using the command line as illustrated below.

When starting a new training run, Asparagus will assign the run a unique run_id which can be used to:

1. Restart a failed run
2. Start a training from a pretrained model (however a checkpoint can also be loaded from a path)

3.1 Pretraining

Pretraining with the default pretraining config:

asp_pretrain task=PT003_LauritSyn \
    +model=unet_b_lw_dec \
    data.train_split=split_75_15_10

3.2 Training from scratch

Training a classification/regression/segmentation model with the default training config:

asp_train_cls task=CLS004_Parrots \
    +model=unet_tiny \
    data.train_split=split_75_15_10

asp_train_reg task=REGR004_Parrots \
    +model=unet_tiny \
    data.train_split=split_75_15_10

asp_train_seg task=SEG004_Parrots \
    +model=unet_tiny \
    data.train_split=split_75_15_10

Training with a pre-defined config:

asp_train_cls --config-name my_dummy_config

Restarting a failed run — find the run_id and rerun with the same command plus run_id=123:

asp_train_cls task=CLS004_Parrots \
    +model=unet_tiny \
    data.train_split=split_75_15_10 \
    run_id=123

3.3 Finetuning

Finetuning from a checkpoint with a run_id:

asp_finetune_cls task=CLS004_Parrots \
    checkpoint_run_id=435850 \
    load_checkpoint_name=best.ckpt

asp_finetune_seg task=SEG004_Parrots \
    checkpoint_run_id=435850 \
    load_checkpoint_name=best.ckpt

asp_finetune_reg task=REGR004_Parrots \
    checkpoint_run_id=435850 \
    load_checkpoint_name=best.ckpt

Or from a direct checkpoint path:

asp_finetune_cls task=CLS004_Parrots \
    checkpoint_path=/path/to/model.ckpt

4. Testing

asp_test_seg test_task=SEG004_Parrots \
    checkpoint_run_id=1234 \
    load_checkpoint_name=last.ckpt \
    test_split=TEST_75_15_10

asp_test_cls test_task=CLS004_Parrots \
    checkpoint_run_id=1234 \
    load_checkpoint_name=best.ckpt \
    test_split=TEST_75_15_10

asp_test_reg test_task=REGR004_Parrots \
    checkpoint_run_id=1234 \
    load_checkpoint_name=best.ckpt \
    test_split=TEST_75_15_10

Contributing

See Contributing for full details on the PR workflow, branch strategy, and code style requirements.
